Descripción del Producto
BH SL1 3.5
Talla SM
| Cuadro |
Cuadro SL1 Disc ICR Monocoque
|
Horquilla SL1 Disc Full Integrated Tapeder, Full Carbon 1.5´
|
||||
| Grupo Cambio |
Manetas cambio Shimano 105 Hydra
|
Cambio trasero Shimano 105 RD7100 12sp
|
Desviador Shimano 105 7100
|
Pedalier Shimano 105 FCR7100 52/36
|
Cassette Shimano 105 11/34
|
Cadena Shimano 105
|
| Frenos |
Freno delantero Shimano 105 Hydraulic
|
Freno trasero Shimano 105 Hydraulic
|
||||
| Ruedas |
Set ruedas Shimano RS171 Disc
|
Cubiertas Hutchinson Nitro 700x 28
|
||||
| Sillín |
Sillin San Marco Monza Start
|
Cierre sillin SL1 integrated
|
Tija BH Lite 27,2
|
|||
| Cockpit |
Manillar BH Lite Compact
|
Potencia BH SL
|
Dirección FSA ICR
|
SL1 3.5
LR355
| XS | SM | MD | LA | XL | |||
|---|---|---|---|---|---|---|---|
| H1 – ST LENGTH | 398 | 433 | 463 | 493 | 504 | ||
| H2 – HT LENGTH | 108 | 120 | 150 | 185 | 196 | ||
| H3 – FORK LENGTH | 369 | 369 | 369 | 369 | 369 | ||
| H4 – TT LENGTH | 510 | 544 | 557 | 570 | 586 | ||
| H5 – FRONT CENTER | 565 | 577 | 580 | 593 | 603 | ||
| H6 – CHAINSTAY LENGHT | 410 | 410 | 410 | 410 | 410 | ||
| H7 – WHEEL BASE | 963,3 | 978,4 | 981,6 | 994,3 | 1005,1 | ||
| H8 – BB DROP | 74,5 | 65 | 65 | 65 | 64,7 | ||
| A1 – ST ANGLE | 74,8 | 72,5 | 72,5 | 72,5 | 72 | ||
| A2 – HT ANGLE | 71,8 | 72 | 73 | 73 | 73 | ||
| reach | 382 | 383 | 384 | 386 | 396 | ||
| stack | 517 | 523 | 549 | 583 | 594 |
